Braid Reinforced Silicone Tubing
Braid reinforced silicone tubing, also known fiberglass woven silicone tubing is usually composed of two layers of silicone tubing, one inside and one outside, sandwiching a layer of woven fiberglass thread in the middle. This layer of braided wire not only serves as a support, but also enhances the overall compressive strength of the silicone tube. For example, in two layers of silicone tubing, there is a layer of fiberglass braided wire reinforcement structure in the middle.
Description
Performance characteristics of braid reinforced silicone tubing
1.Strong pressure resistance: Braided wire can provide support and is a common high pressure resistant silicone tube that can withstand large pressures and meet the needs of special environmental operations.
2.Wide temperature resistance range: It can withstand extreme temperatures, such as the temperature range of fiberglass braided silicone tubing for oxygen concentrators, which is -60 ° C to 200 ° C, and can adapt to various high and low temperature environments.
3.Good chemical stability: resistant to chemicals, ozone, radiation, etc., with stable performance in complex chemical environments.
4.Hygiene and Environmental Protection: It belongs to non-toxic and odorless silicone tubing, with high hygiene and environmental protection level and low volatility, suitable for pharmaceutical and biomedical applications that require high hygiene requirements. It does not transmit odorless or tasteless liquids during transportation.
Application area of braid reinforced silicone tubing
1.Industrial field: used in high-temperature areas of metallurgy, shipbuilding, and chemical industries to wrap and protect cables and fluid pipelines; It is also used for high-temperature insulation protection in electronic wiring, electromechanical matching, terminal connection, pipeline anti-corrosion, computer peripherals, electrical instruments, power communication, navigation and aerospace, optoelectronic communication, automobiles and other fields, as well as insulation protection equipment such as H&N grade motors, household appliances, electric heating equipment, special lamps, etc
advertisement
2.Food field: It is a type of silicone wire clamp tube and food grade braided tube used for food and beer transportation. It is non-toxic and used for visual monitoring of solution flow.
3.Laboratory and biotechnology fields: It is an ideal choice for fluid transportation in laboratories, biotechnology, and pharmaceutical factories.
Production process of braid reinforced silicone tubing
During the production of braid reinforced silicone tubing, the inner tube is usually extruded first, then braided, and finally the outer tube is extruded. The middle layer of conventional silicone braided tubes is relatively thin, mostly presenting diamond shaped braiding, which can be seen through by the naked eye; The outer woven fiberglass silicone tube used for steam equipment has a very dense woven fabric on its surface, which is wrapped in all directions and cannot see the inner tube. Moreover, the outer woven fiberglass silicone tube adopts a dip coating process after weaving, wrapping the outer surface of the woven fabric with a layer of liquid silicone to withstand high temperature and high pressure and prevent the woven fabric from falling off and becoming loose; The conventional silicone braided tube is extruded from the outer tube again after braiding, wrapping the braided material between the inner and outer tube walls
